Linear Supervised Wireless Security Console DVS-1200


Linear 12-Channel Supervised Wireless Security Console DVS-1200

Out of stock

SKU: DVS-1200 Categories: , , ,

The Model DVS-1200 12-channel Supervised Wireless Security Console is a wireless console intended for apartments, condos, townhouses, homes, and any other sites that require 12 zones of protection or less. The system features a full-function, built-in keypad with an LED display of each sensor/transmitter. The DVS-1200 is a uniquely-styled, ultra-compact, UL listed console with a concealed antenna for surface, flush, or tabletop mounting. The heart of the console is a superheterodyne radio receiver. A rechargeable back-up battery also fits inside the console.

The Model DVS-1200 has six operating modes and can be configured for one-button operation, for eight user codes (including duress), and to the SIA false alarm standard.

An optional plug-in Model VB-2 board adds valuable communications capabilities, including voice prompts, touch-tone telephone access, and a two-way voice link for central station monitoring. Compatibility with the industry’s widest line of transmitters and sensors (Linear’s supervised DXS series and non-supervised DX series) means systems can be tailored by site and by need. Available models include door/windows, smokes, glass breaks, bill traps, keypads, and single and multi-channel personal transmitters in a variety of styles (handhelds, pendants, minis, and wristbands).

Installation and programming are made easy by Linear’s RA-2400 remote access software.



    Primary Operating Voltage: 120 VAC, 60 Hz
    Transformer: UL listed, Class II, plug-in, 16 VAC, 1.25 A (supplied)
    Back-Up Battery: 1.2 Amp-hour, 12 VDC
    Type: Superheterodyne
    Operating Frequency: 315 MHz ± 100 Kc
    Sensitivity: -100 dB minimum
    Antenna Type: Counterpoised bipolar design
    Compatible RF Formats: Linear DX, DXS
    Radio Zones: 12 supervised
    PAC Codes: Eight total, including Duress, Installer, five User and Page Alert
    Operating Modes: Off, Chime, Home, Home Instant, Away, and Test
    Sensor Types: 11 including Automation, Emergency, Panic, Fire, Perimeter, Exit/Entry, Interior Chime Only, Arm/Disarm A, Arm/Disarm B, and Environmental
    Auxiliary Outputs: Automation, External Console Speaker, and External Alarm Siren
    Memory: EEPROM retains system programming during total power failure
    Operating Temperature: 32° to 120° F (0° to 49° C)
    Dialing: DTMF or pulse dialing; pulse speed (10 PPS, 60% break, 40% make)
    Ringer Equivalence: 0.4 B
    Reporting Formats: 4 x 2, 40 PPS, or Ademco Contact ID
    Telephone Numbers: Primary, secondary, and supervisory
    Reports: Full zone reports, console reports, general system reports, forced arming, and duress PAC
    Dimensions: 10.5 in H x 7.75 in W x 2.87 in D (267 x 197 x 73 mm)
    Weight: 3 lbs. (1.36 kg)


  • Uniquely-styled, ultra-compact console with concealed antenna
  • Surface, flush or tabletop mounting
  • 1-button arming and many other user amenities
  • Optional voice prompts, touch-tone telephone access, and 2-Way voice
  • Quick learn transmitters and windows-based programming via RA-2400 software
  • Superheterodyne receiver with up to 1,500 foot range
  • Full complement of DX and DXS transmitters for up to a 12 zone system
  • Backup battery size: 12 volts, 1.2 Amp/hour
  • UL Listed
  • Operating Frequency: 315 MHz
  • 10.5″ H x 7.75″ W x 2.87″ D
